Medispirex
Medispirex
| Product name | Model | Material | Specification | Code |
|---|---|---|---|---|
| Elastic Nail Intramedullary Nail | SNXS | Titanium Alloy | 2.5×440 | 15902940 |
Intramedullary Nail Key Features:
| Product name | Model | Specification | Material | Code |
|---|---|---|---|---|
| Proximal Femoral Nail Antirotation Intramedullary Nail | SGM-IIK | 9.0×170×130° | Titanium Alloy | 15649170 |
| Proximal Femoral Nail Antirotation Intramedullary Nail | SGM-IIK | 9.0×200×130° | Titanium Alloy | 15649200 |
| Proximal Femoral Nail Antirotation Intramedullary Nail | SGM-IIK | 9.0×240×130° | Titanium Alloy | 15649240 |
| Proximal Femoral Nail Antirotation End Cap | SGM-IIK | 10×15 | Titanium Alloy | 15601115 |
| Proximal Femoral Nail Antirotation End Cap | SGM-IIK | 10×20 | Titanium Alloy | 15601120 |
| Proximal Femoral Nail Antirotation Blade | SGM-IIK | 10.5×70 | Titanium Alloy | 15600570 |
| Proximal Femoral Nail Antirotation Blade | SGM-IIK | 10.5×80 | Titanium Alloy | 15600580 |
| Proximal Femoral Nail Antirotation φ4.9 locking screw | SGM-IIK | 4.9×30--72 | Titanium Alloy | 15604930 |
| Femoral Nail locking screw I | SGG-IIIK | 6.5×75 | Titanium Alloy | 15246575 |
| Femoral Nail Intramedullary Nail | SGG-IIIK | 9.0-13.0 | Titanium Alloy | 15249340 |
| Humeral nail Intramedullary Nail | SHG-IK | 8 | Titanium Alloy | 15728160 |
The nail length is engineered to be fully consistent with the anatomical structure of the FEMORAL medullary cavity.
Specially designed to further improve the fixation strength of osteoporosis. The blunt end design of the locking screw reduces the risk of excessive penetration.
Short nail: diameter of 8.0/ 9.5mm, length of 160mm.
Long nail: diameter of 7.0/ 8.5mm, length of 180-315mm (15mm interval).
All nails are available in left and right types, constructed from biocompatible titanium alloy. The diameter is suitable for all applications. Implantation features simple operation and minimally invasive technique.
Multi-plane and Multi-locking screw fixation options, offering multiple options for operation to achieve optimal fixation stability. Features a screw-in-screw design to further improve the fixation strength of osteoporosis. The blunt head of the locking screw design reduces the risk of excessive penetration, while the locking screw countersinking design reduces soft tissue irritation.
Short screw: Two different plane holes for locking.
Long screw: Three locking holes located in the safe area between the median nerve and the radial nerve, avoiding critical blood vessels. Two anterior and posterior locking holes facilitate manual operation, minimizing the occurrence of rotation and displacement of distal fractures.
Nail diameter should measure 30-40% of the narrowest transverse diameter of the medullary cavity. Suggested application values: 3.0mm for ages 6-8 years; 3.5mm for ages 9-11 years; 4.0mm for ages 12-14 years.
Special design of compression holes helps to increase the stability of transverse or short oblique fractures. Features a self-sustaining compression mechanism; no static screw is needed to maintain compression during surgical operation.
Compared with G3 with a radian radius of 1.5m, the distal location of TFNA with a radian radius of 1.0m in the center of the medullary cavity is twice as likely as that of the G3 system.
Q1: Would you please give some information on shipping mode and charges?
Normally we send through courier like DHL, FEDEX, UPS, TNT etc., or post upon request from clients.
Q2: Do you have ISO9001, ISO 13485, CE approvals?
Yes, our manufacturing practices and products conform to international medical device production standards including ISO9001, ISO 13485, and CE.
Q3: What is the minimum order that we can place? Do you provide free samples?
We expect your minimum orders to be at least US$500. However, we understand that customers need to place smaller sample orders in the beginning in order to test our products in their market. We can offer free samples, but the cost of freight is not covered.
Q4: Can I buy products not shown but similar to your catalogue?
Of course you can, just send us pictures or samples. Please note that custom requests may take a little longer time for delivery.
Q5: Do you have stock for listed products, or are they newly produced? What are your terms of payment?
Generally, we have stock for listed products, which are produced monthly. However, it depends on sales conditions. We advise asking our sales team for accurate inventory information. Payment <= 800USD requires 100% in advance. Payment > 800USD requires 30% T/T in advance and the remaining balance before shipment. Payment methods include L/C, T/T, Western Union, and PayPal.
Q6: What material is used for the orthopedic implants and nails?
All our intramedullary nails, including the Elastic Nails and TFNA Systems, are manufactured from high-quality, medical-grade Titanium Alloy to ensure optimal biocompatibility and high mechanical strength.
