Geasure Titanium Alloy Interlocking Nail Orthopedic Implant for Proximal Bone Fixation and Interventional Surgery Solutions

Orthopedic Implant Intramedullary Nail System

Intramedullary Nail: All kinds of high quality intramedullary nails. Easy to insert and take out; Titanium alloy material; Reduce the risk of outer wall impact and main nail inward movement; The diameter is suitable for all applications; Simple operation and minimally invasive implantation.

Product name	Model	Material	Specification	Code
Proximal Femoral Nail Antirotation Intramedullary Nail (non sterilization)	SGM-IIK	Titanium Alloy	10.0×320×130° Left	15640320

Product name	Model	Specification	Material	Code
Proximal Femoral Nail Antirotation Intramedullary Nail	SGM-IIK	9.0×170×130°	Titanium Alloy	15649170
Proximal Femoral Nail Antirotation Intramedullary Nail	SGM-IIK	9.0×200×130°	Titanium Alloy	15649200
Proximal Femoral Nail Antirotation Intramedullary Nail	SGM-IIK	9.0×240×130°	Titanium Alloy	15649240
Proximal Femoral Nail Antirotation End Cap	SGM-IIK	10×15	Titanium Alloy	15601115
Proximal Femoral Nail Antirotation End Cap	SGM-IIK	10×20	Titanium Alloy	15601120
Proximal Femoral Nail Antirotation Blade	SGM-IIK	10.5×70	Titanium Alloy	15600570
Proximal Femoral Nail Antirotation Blade	SGM-IIK	10.5×80	Titanium Alloy	15600580
Proximal Femoral Nail Antirotation φ4.9 locking screw	SGM-IIK	4.9×30--72	Titanium Alloy	15604930
Femoral Nail locking screw I	SGG-IIIK	6.5×75	Titanium Alloy	15246575
Femoral Nail Intramedullary Nail	SGG-IIIK	9.0-13.0	Titanium Alloy	15249340
Humeral nail Intramedullary Nail	SHG-IK	8	Titanium Alloy	15728160

Our Advantages

1. 1.0m Radian Radius

The length is consistent with the anatomy of the FEMORAL medullary cavity.

2. Screw-in-Screw Design

To further improve the fixation strength of osteoporosis. The Blunt End Design of the locking screw reduces the risk of excessive penetration.

3. Complete Specifications

Short nail: diameter of 8.0 / 9.5mm, length of 160mm.
Long nail: diameter of 7.0 / 8.5mm, length of 180-315mm (15mm interval).
All nails have left and right type, titanium alloy material. The diameter is suitable for all applications. Simple operation and minimally invasive implantation.

Details Images

Proximal Fixation

Multi-plane and Multi-locking screw fixation options, multiple options for operation, to achieve optimal fixation stability. Screw-in-screw design to further improve the fixation strength of osteoporosis. Blunt head of locking screw design to reduce the risk of excessive penetration. Locking screw countersinking design to reduce soft tissue irritation.

Distal Fixation

Short screw: two different plane holes for locking. Long screw: three locking holes avoid important blood vessels, located in the safe area between the median nerve and the radial nerve. Two anterior and posterior locking holes facilitate the manual operation, minimizing the occurrence of rotation and displacement of distal fracture.

Elastic Nail

Nail diameter should be 30-40% of the narrowest transverse diameter of medullary cavity. Apply to 3mm / 6-8 years old; 3.5mm / 9-11 years old; 4.0mm / 12-14 years old.

Compression

Special design of compression holes helps to increase the stability of transverse or short oblique fractures. Self-sustaining compression mechanism, no static screw is needed to maintain compression during operation.

TFNA System

Compared with G3 with radian radius of 1.5m, the distal location of TFNA with radian radius of 1.0m in the center of medullary cavity is twice as likely as that of G3.

Orthopedic Medical Devices

Manufacturing Facilities

Frequently Asked Questions

Would you please give some information on shipping mode and charges?

Normally we send through courier like DHL, FEDEX, UPS, TNT etc. or post upon request from clients.

Do you have ISO9001, ISO 13485, and CE approvals?

Yes, our products are certified and manufactured in compliance with international quality standards including ISO9001, ISO 13485, and CE approvals. Detailed certification documents can be shared upon client request.

What is the minimum order that we can place? Do you provide free samples?

We expect your minimum orders to be at least US$500. However, we understand that customers need to place smaller sample orders in the beginning in order to test market our products. We could offer free samples, but do not pay the cost of freight.

Can I buy products not shown but similar to your catalogue?

Of course you can, just send us pictures or samples. But this takes a little longer time for delivery.

Do you have stock for listed products, or are they newly produced?

Generally, we have stock for every listed product, which is produced monthly. But it depends on our sales conditions. It is best to ask our sales representative for accurate inventory information.

What are your terms and methods of payment?

For payments less than or equal to 800 USD, 100% in advance is required. For payments greater than 800 USD, 30% T/T in advance is required, with the remaining balance due before shipment. Accepted payment methods include L/C, T/T, Western Union, and PayPal.
